D-link DMC-540SSC Fiber media converter
Original price was: KSh6,500.00.KSh6,000.00Current price is: KSh6,000.00. + VAT
- Supports Single-mode Fiber Cable Distance Up To 40 km
- 1 x 10/100BASE-TX RJ-45 port & 1 x 100BASE-FX SC port
- Auto-MDI/MDIX
- Can be used as a stand-alone device or installed in a chassis
- Fibre Wavelength: 1310 nm
D-link DMC-540SSC Fiber media converter
The D-Link DMC-540SSC is a reliable and efficient media converter designed to bridge your network’s copper and fiber segments, offering a seamless and cost-effective solution for long-distance data transmission.
With support for one 10/100 Mbps RJ-45 port and a 100BASE-FX SC port, this device converts fast Ethernet from twisted-pair copper to single-mode fiber, enabling links up to 40 km. Built with plug-and-play simplicity, auto-MDI/MDIX, and flexible deployment options (standalone or in a chassis), it’s ideal for extending network reach without compromising performance.
Specification
| DMC-540SSC | ||
| Interface | ||
| Number of Ports | • 1 x 10/100BASE-TX RJ-45 port • 1 x 100BASE-FX SC port | |
| Standards | • IEEE 802.3 for 10BASE-T/F • IEEE 802.3u for 100BASE-TX/FX | |
| Data Transfer Rate | • Ethernet: 10 Mbps/20 Mbps (half duplex or full-duplex) • Fast Ethernet: 100 Mbps/200 Mbps (half duplex or full duplex) | |
| Duplex Mode | • Half-duplex/full-duplex | |
| Media Types | • 10BASE-T: 2-pair Cat. 3/4/5/5e, Unshielded Twisted Pair (UTP) (up to 100 m) • 10/100BASE-TX: 2-pair Cat. 5/5e, Unshielded Twisted Pair (UTP) (up to 100 m) • 100BASE-FX: Multi-mode fi optic cable with SC connector (up to 40 km) | |
| Media Exchange Interface | • Auto-MDI/MDIX | |
| Functionality | ||
| Transmission Mode | • Store-and-forward | |
| Forwarding Rate | • Full wire speed forwarding rate | |
| Physical | ||
| Diagnostic LEDs | • Power • Speed (for twisted pair ports) • Full-duplex/Collision (for twisted pair and fi ports) • LINK/ACT (for twisted pair ports) | |
| AC Input | • 5 V/1 A external power adapter | |
| Temperature | • Operating: 0 °C to 50 °C • Storage: -20 °C to 70 °C | |
| Humidity | • 5% to 90% RH, non-condensing | |
| Dimensions | • 95x 70 x 26 mm | |
| Fiber Wavelength | • 1310 nm | |
| Supported Fiber Cable Length | • Up to 40km | |
| Emission Certifi tions (EMI) | • FCC | |
