MIKROTIK RB921GS 5HPACD MANTBOX ANTENNA
Original price was: KSh40,000.00.KSh37,800.00Current price is: KSh37,800.00. + VAT
KEY FEATURES
5GHz 120 degree 19dBi dual polarization sector Integrated antenna with 720Mhz CPU, 128MB RAM, SFP, PSU and PoE
Buy Online at Best Prices in Nairobi Kenya
MIKROTIK RB921GS 5HPACD MANTBOX ANTENNA SPECIFICATIONS AND DETAILS
Overview
The mANTBox is based on our new mANT sector antennas, but also has a wireless router built right in. Powered by the RB921 device, the mANTBox comes ready to use with everything included. The device uses a high speed 720MHz CPU and has a built in 802.11 ac/a/n wireless device with up to 31dBm output power.
mANTBox 19s comes with 19dBi 120 degree sector antenna.
We have two versions available – RB921GS-5HPacD-19S (International) and RB921GS-5HPacD-19S-US (USA). The factory locks the RB921GS-5HPacD-19S-US (USA) for the 5.17 – 5.25 GHz and 5.725 – 5.835 GHz frequencies, and this lock cannot be removed. RB921GS-5HPacD-19S (International) supports 5.17 – 5.835 GHz range (Specific frequency range can be limited by country regulations).
Tech Specifications
| Details | |
| Product code | RB921GS-5HPacD-19S |
| Architecture | MIPSBE |
| CPU | QCA9557 |
| CPU core count | 1 |
| CPU nominal frequency | 720 MHz |
| Dimensions | 152 x 598 x 78 mm |
| RouterOS license | 4 |
| Operating System | RouterOS |
| Size of RAM | 128 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200’000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| Suggested price | $199.00 |
Powering
| Details | |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 8-30 V |
| Max power consumption | 13 W |
| Cooling type | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 12-28 V |
Wireless specifications
| Details | |
| Wireless 5 GHz Max data rate | 867 Mbit/s |
| Wireless 5 GHz number of chains | 2 |
| Wireless 5 GHz standards | 802.11a/n/ac |
| Antenna gain dBi for 5 GHz | 19 |
| Wireless 5 GHz chip model | QCA9892 |
| Wireless 5 GHz generation | Wi-Fi 5 |
Ethernet
| Details | |
| 10/100/1000 Ethernet ports | 1 |
Fiber
| Details | |
| SFP ports | 1 |
Other
| Details | |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
Certification & Approvals
| Details | |
| Certification | CE, FCC, IC, EAC, ROHS |
Wireless specifications
| 5 GHz | Transmit (dBm) | Receive Sensitivity |
| 6MBit/s | 31 | -96 |
| 54MBit/s | 27 | -81 |
| MCS0 | 30 | -96 |
| MCS7 | 27 | -77 |
| MCS9 | 22 | -72 |
